Connector Description
JTPM1 Trusted Platform Module/Port 80 Connector
LAN1, LAN2 Back Panel LAN1, LAN2 Connectors
M.2-H1, M.2-H2 M.2 Slots
NVMe0/1 PCIe1A NVMe Ports 0/1, PCIe Port 1A
NVMe2/3 PCIe1B NVMe Ports 2/3, PCIe Port 1B
NVMe4/5 SATA0-7 NVMe Ports 4/5 or SATA Ports 0-7
PCIE SLOT1, 3, 5 PCIE Slot PCIe 5.0 x16
PCIE SLOT2, 4 PCIE Slot PCIe 5.0 x8
PWRI2C Power Supply SMBus I
2
C Header
SATA0–7 SATA 0–7 via JMCIO3
SATA8, SATA9, SATA10, SATA11 Onboard SATA Ports 8–11
SATA12–13; 14–15 Onboard SATA ports 12–13; 14–15
USB0/1 (3.0) Back Panel USB 3.0 Ports (USB0/1)
USB2/3 (3.0) Back Panel USB 3.0 Ports (USB2/3)
USB4/5 (3.0) Internal USB 3.0 header (USB4/5)
VGA Back Panel VGA Port
Note: Jumpers, connectors, switches, and LED indicators that are not described in these
tables are for manufacturing testing purposes only, and are not covered in this manual.
15
H14SSL-N/NT: Introduction
