3. Lift up the rail frame until it securely rests in upright position. Then remove the PnP cover
cap from the socket below. Grip the two lift tabs marked "Remove" at the middle of the
cap and pull vertically upwards to remove the PnP cover cap.
Important: The exposed socket contacts are extremely vulnerable and can be
damaged easily. Do not touch or drop objects onto the contacts and be careful
removing the PnP cover cap and when placing the rail frame over the socket.
4. Gently lower the rail frame down onto the socket until the latches on the rail frame
engage with the socket housing and it rests in place. Do not force it into place! Note that
the force frame is spring loaded and must be held in place before it is secured.
32
H14DSG-OD: Component Installation
