Quick Reference Table
Jumper Description Default Setting
JBT1 CMOS Clear Open (Normal)
JPFR1 PFR Function Open (Normal)
JPFR2 PFR Function Open (Normal)
JPFR3 PFR Function Open (Normal)
JPG1 VGA Enable/Disable Pins 1-2 (Enable)
JUID1 Switch Function UID/Reset Pins 1-2 (UID)
LED Description Status
LED1 Power LED Solid Green: Power On
LED2 Rot Status LED
Off: Normal
Red on: Fail
LED3 BMC Heartbeat LED
Green: Blinking (BMC Normal)
Green: Fast Blinking (BMC Initializing)
Connector Description
FAN1-FAN5 6-pin System Cooling Fan Headers
JFP1 Front Control Panel Connector
JLC0-3 2-pin 2.048 V Header for Liquid-Cooled Solution
JMCIO_P0G3A
JMCIO_P0G3B
PCIe 5.0 x8 (Processor 1)
JMCIO_P1G1A
JMCIO_P1G1B
PCIe 5.0 x8 (Processor 2)
JMCIO_P1P4
PCIe 3.0 x4 (Processor 2) for M.2 Module
(AOC-SMG4-2M2 or AOM-S3808NI-4NM)
JNIC1-JNIC6 PCIe Connections to NIC Card Carrier Board (AOM-DP805-LPIO)
JNCSIBF3 NCSI Connector
JNVME1-4
PCIe 5.0 x8 Ports to Backplane
(Vpp available through JNVME1 and JNVME3)
14
H14DSG-OD: Introduction
