Chapter 1: Introduction Chapter 1: Introduction
Figure 1-4. Components Labeled (SBI-621E-1NE34 model shown)
Top view
DIMMs
Processor and
Heatsink
DIMMs
Drives
Processor and
Heatsink
Space for PCIe
.Expansion Cards
Mezzanine
Connector
Figure 1-5. Components, (SBI-621E-1NE38 shown)
Blade Components
Item Feature Description
1 Drives
SBI-621E-1NE34: four hot-swap E3.S (7.5 mm) drives
SBI-621E-1NE38: eight hot-swap E3.S (7.5 mm) drives
2 CPU Processors and heatsinks
3 DIMMs 32 memory slots, DDR5
4 Cover Partial chassis cover
5 Mezzanine Network mezzanine add-on card
Expansion Cards SBI-621E-1NE34 only: space for two PCIe cards
5 4
1
2
3
2
3
1
3
3
