1.1 Overview

The SBI-422B-1NE14-5NE14 blade is a compact self-contained server that connects into a

precabled enclosure that provides power, cooling, management and networking functions. One

enclosure can hold ten single width blades.

In this manual, “blade” or “blade unit” refers to a single blade, and “blade enclosure” is the

chassis that houses the blades, power supplies and other modules. “Blade system” refers to

the enclosure, blades units, and various management and networking modules.

System Overview

Motherboard B14DBT Rev 1.01

Processor

Dual Socket E2 (LGA-4710)

®

Xeon

®

6700/6500-series processors with P-cores

or E-cores

Memory

16 DDR5 DIMM slots

Up to 4TB DDR5ECC RDIMM/3DS-RDIMM, with speed 6400MT/s (1DPC) or

5200MT/s (2DPC) in 16 DIMM slots

Up to 512GB MRDIMM with speed 8000MT/s in 1DPC memory population

Drive Support

Four E1.S drives

One NVMe M.2 2280 (onboard)

Expansion

Cards

One AIOM PCIe Gen5 x16 slot

I/O Ports One TPM 2.0 Header

System Cooling Air cooled

Form Factor

SBI-422-1NE14: 1.7" x 6.55" x 23.9" inches (4.32 x 16.64 x 60.71 cm)

SBI-422-5NE14: 3.4" x 6.55" x 23.9" inches (8.64 x 16.64 x 60.71 cm)

Eligible Enclosures

l

SBE-820C-822/622/422, SBE-820L-822/622/422, SBE-820J-822/622/422

l

SBE-820J2-822/622, SBE-820J2-830/630, SBE-820H-822/622, SBE-820H2-830/630

14

Blade Server SBI-422B-1NE14-5NE14: Introduction
