Connector Description
JSMBUS1 SMBus/ I²C Header
JSPKR1 Speaker-out with 3 W Amplifier
LVDS1 Low Voltage Differential Signaling Connector (LVDS)
M.2-B1
M.2 B-Key 2242/2280/3052 Slot with Nano SIM and 5G support (PCIe 3.0 x1/SATA
3.0/USB 3.0/USB 2.0)
M.2-E1 M.2 E-Key 2230 Slot (PCIe 3.0 x1/USB 2.0/CNVi )
M.2-M1 M.2 M-Key 2242/2280 Slot (SATA 3.0/PCIe 3.0 x1)
USB1/2,
USB3/4
USB 3.2 (10 Gb/s) Type-A ports on the rear I/O ports
USB5/6 USB 2.0 Header
LED Description Status
LED1 Power LED
Green: System on
Red: S5 or main power fail
Off: System off
Motherboard Features
CPU
l
A4SAN-H/-WOHS supports an Intel
®
Atom
®
Processor x7835RE
l
A4SAN-E/-WOHS supports an Intel Atom Processor x7433RE
l
A4SAN-L/-WOHS supports an Intel Processor N97
Memory
l
Supports up to 16 GB of Non-ECC DDR5 SO-DIMM with speeds of up to 4800 MT/s in a
single slot
DIMM Size
l
16 GB
19
A4SAN-H/-E/-L/-WOHS: Introduction
