SMBus Header
A System Management Bus header for additional slave devices or sensors is located at
JSMBUS1.
For a detailed diagram of the A4SAN-H/-E/-L/-WOHS motherboard, see the layout under
"Quick Reference" on page 11.
SMBus Header
Pin Definitions: Four Total
Pin# Definitions
1 SMB_CLK
2 SMB_DATA
3 GND
4 5 V
Speaker Header
The speaker-out with a 3 W amplifier ( JSPKR1) is used to amplify low-power electronic audio
signals to a level that is high enough for current driving loudspeakers and headphones.
For a detailed diagram of the A4SAN-H/-E/-L/-WOHS motherboard, see the layout under
"Quick Reference" on page 11.
Speaker Header
Pin Definitions: Four Total
Pin# Definition
1 SPEAKER_LN_OUT
2 SPEAKER_LP_OUT
3 SPEAKER_RN_OUT
4 SPEAKER_RP_OUT
USB Header
The motherboard has one front-accessible USB 2.0 header (USB5/6). The onboard header
provides front-side USB access with a cable.
For a detailed diagram of the A4SAN-H/-E/-L/-WOHS motherboard, see the layout under
"Quick Reference" on page 11.
