Quick Reference Table
Jumper Description Default Settings
JLCDPWR1 LVDS Panel VCC Power 3.3 V/5 V
Pins 1–3 (3.3 V)
Pins 3–5 (5 V)
JPME2
CMOS Clear
ME Manufacturing Mode
Pins 1–3 (Normal)
Pins 3–5 (Clear CMOS)
Pins 2–4 (Manufacturing Mode)
Pins 4–6 (Normal)
JPT1
Onboard TPM 2.0 Enable/Disable
Force Power On
Pins 1–3 (Enabled)
Pins 3–5 (Disabled)
Pins 2–4 (Force Power On)
Pins 4–6 (Power On by power button)
JSIM1_OPT
USB or PCIe Interface Optional
SIM Detect
M.2 B-Key Storage LED
Pins 1–3 Short (USB)
Pins 1–3 Open (PCIe)
Pins 2–4 Short (Low Active)
Pins 2–4 Open (High Active)
Pins 5–6 Enable
Connector Description
AUDIO FP Front Panel Audio Header (Line-out, Mic-in)
BT1 CMOS Battery Header
FAN1 Fan Header
JCOM1,
JCOM2
JCOM1: COM1/2 header for two RS232/422/485
JCOM2: COM3/4 header for two RS232
JHDMI1,
JHDMI2
HDMI 1.4b Ports
JF1 Front Control Panel Header
JGP1 General Purpose I/O Header
JLAN1, JLAN2 2.5G LAN Ports
JPW1 9 V to 36 V Power-in Connector
JPOE1 Power Over Ethernet (PoE) Power Internal Connector
JSIM1 Nano SIM Card Slot
18
A4SAN-H/-E/-L/-WOHS: Introduction
