14
Super A2SAN-H/-E/-L and X11SAN User's Manual
Quick Reference Table
Jumper Description Default Setting (*)
JLCDPWR1 LVDS Panel VCC Power 3.3V / 5V / 12V
Pins 1-3* (3.3V)
Pins 3-5 (5V)
Pins 3-4 (12V)
JPF1 Power Force On
Pins 1-2* (Power Force On)
Pins 2-3 (PWR BTN Power On)
JPME2 Manufacturing Mode
Pins 1-2* (Normal)
Pins 2-3 (Manufacturing Mode)
JPT1 TPM Enable/Disable Header
JPT1_1N2* (Enable)
JPT1_3N4 (Disable)
LED Description Status
LED1 Power LED (for debugging only)
Solid Green: S0 mode
Solid Red: S3/S4/S5 modes
Connector Description
AUDIO FP Front Panel Audio Header (Mic-in/Headphone-out)
BT1
Battery Connector
(To Clear CMOS, remove the battery, short pins 1-2 for more than 10 seconds and
install the battery.)
FAN1 System Fan Header
I-SATA1 Intel® PCH SATA 3.0 Port
JCOM1: COM1/COM2
JCOM2: COM3/COM4
JCOM3: COM5/COM6
Serial COM Ports (JCOM1 supports RS232/RS422/RS485)
Serial COM Ports (JCOM2 supports RS232)
Serial COM Ports (JCOM3 supports RS232) (Only supported on A2SAN-H-WOHS)
JD1 Speaker Header
JF1 Front Control Panel Header
JGP1 General Purpose I/O Header
JHDMI Back Panel HDMI Port
JIP1 LVDS Inverter Power Header
JLPC80 Port 80 Connector (for debugging only)
JMD1 M.2 Slot (B-KEY) (supports PCIe Gen2 x 1 / SATA / USB 2.0)
JMP1 Mini PCI-E Slot (supports PCIe Gen2 x 1 / USB 2.0)
JPH1 SATA Power Connector (for one HDD system)
JPW1 4-pin 12V-Standby R/A Type Power Connector
JPW2 12V DC Power
JSMBUS1 System Management Bus Header
JLAN1: LAN1/LAN2 LAN (RJ45) Ports
LVDS1 Dual Channel 48-bit LVDS Connector
USB4/5 Back Panel Universal Serial Bus (USB) 3.0 Ports
USB0/1, USB2/3 USB 2.0 Headers
USB6 USB 3.1 Type-C Header
VGA Back Panel VGA Port
