4 Mechanical Mounting User Manual
(A) Mounting-bracket (B) Full threaded bolt (C) Metal bracket
(D) Flat washer (E) Spring washer (F) Hex nuts
- - End
4.5.2 Pole-Mounting
Tools
Item Specification
Phillips screwdriver M4
Marker —
Level —
Electric drill * Drill bit: φ12
Wrench Opening: 16 mm
* Check whether other tools are needed according to the specification of clamp bolts.
Spare parts
Item Quantity Specification Source
Grub screw 2 M4×10 Delivery scope
Bolt assembly 4 M10 Delivery scope
Nut assembly 4 M10 Self-prepared
U-beam 2 — Self-prepared
Clamp 2 Determined by pole size Self-prepared
step 1 Bury the pole into the installation site.
Please skip this step if the inverter is to be installed on a concrete post, PV bracket, etc.
step 2
Assemble the mounting-bracket.
36
