2 Product Description User Manual
LED Color State Definition
On A fault occurs and the device cannot connect to the grid.
Red
Blink
The Bluetooth connection is established, data commu
nication in process, and a system fault occurs.
Gray
OFF Both the AC and DC sides are powered down.
WARNING
Voltage may still be present in AC side circuits after the indicator is off. Pay attention
to the electricity safety when operating.
2.5 DC Switch
The inverter is equipped with four DC switches which can safely disconnect it from PV strings.
Each switch controls the DC terminals in the area where the switch is located.
2.6 Circuit Diagram
The following figure shows the main circuit of the inverter.
12
