b. Mix the primer according to the paint model and the requirements of Table 9-9 Primer
and Finish Paint Selection and Mixing.
c. Apply a primer with a small brush, and use a film thickness meter to ensure the coating
thickness in corners and gaps is between 70μm–80μm.
d. After the first layer dries, apply another layer of primer using a brush in a crosshatch
pattern. Once it is dry, check that the dry film thickness is within 100μm–300μm.
Step 6 Refer to 9.5.2 Finish Paint Repair for finish paint repair.
Step 7 Inspect the paint to ensure it has a uniform color, smooth transitions, and meets the
required film thickness.
--End
When using spray paint, follow these steps:
1. Carefully cover the area outside the damaged spot (extending 800mm outward)
using masking paper.
2. Spray the exposed area with the paint. After the paint dries, check that the dry
film thickness is within the range of 100μm–300μm.
9.6 Replace the Fuse of LV Cabinet
Prerequisite
Overview
The fuse position of LV cabinet is shown in the figure below.
Tools
No.
Name Source
1 Ratchet wrench Scope of supply
2 Torque wrench
Beyond the scope of supply
3 Load switch operating handle
System Manual 9 Routine Maintenance
77
