There is a sealing gasket between the flange cover and the dehydrating breather.
When tightening the bolts, make sure that the height of the gasket shrinks by 1/4.
Figure 7-1 Fit the Dehydrating Breather
Step 3 Remove the oil cup from the dehydrating breather.
Step 4 Fill transformer oil into the oil cup. Then, fit the oil cup back to the dehydrating breather.
Figure 7-2 Fit the Oil Cup
--End
7.1.4 Installing Surge Arrester (Optional)
The instructions below are provided with the surge arrester of the 36kV MV switchgear as
an example. For detailed installation instructions, see the installation guide that comes with
the surge arrester.
System Manual7 Powering up and Powering down
58
