13
1
2
1 2
3
3
1. Remove the cover caps (3) and then remove the door by unscrewing the four screws (1) and (2).
Be careful to hold the door firmly after removing the screws and place it on a padded surface to
avoid the risk of damage.
2. Pop out the cover caps on the left side of the cabinet and use them to cover the screw holes on the
right-hand side.
3. Unscrew and transfer the holes plug and lock bracket to the opposite side of the door.
4. Rotate the door 180° and refit the door to the opposite side. Then screw and tighten it after the door
is leveled.
5. For models with door racks, remove the door racks. Then replace the door racks by rotating them
180° and repeating the steps in reverse.
Adjusting the Height of the Unit
The height of the ADA refrigerators can be increased by up to 3” by turning the adjustable legs. Once
the desired height has been achieved, the gap between the kick-plate and the floor can be covered by
lowering a hidden section of the kick-plate. See the next section for instructions.
Adjusting the Kick Plate (Only for ADA Models)
The pre-fitted kick-plate of the appliance includes an
adjustable kick-plate section that is initially seated behind
the upper section. In order to adjust the kick-plate height,
follow the instructions below:
1. Remove the screws (1) from both the top left- and top
right-hand sides of the kick-plate.
2. Loosen or remove the screws (2) from both the bottom
left and bottom right-hand sides of the kick-plate.
Failure to loosen the bottom screws sufficiently may
cause damage to the lower trim when adjusting it.
3. Carefully guide the lower trim down until the desired
height is achieved.
4. Reinsert screws and tighten them.
1
2
