9
Duct Installation
Remove the Filter
Take out filters from the accessory bag. Tear off film from grease filter. Put charcoal filter on grease
filter. Slip the back edge of the filter into the retaining slot. Rotate the filter block pin to fix the filters
into place.
If you are venting indoors, unscrew the 2 screws holding baffle in place and remove the baffle.
DO NOT REMOVE ANY OTHER VENTING HOLE COVER. If the hood is to be recirculated, skip to
the Cut Holes step.
Remove the Duct Knockout
Using a flat-blade screwdriver, remove the appropriate duct knockout from the top or back of the
hood.
WARNING: Failure to replace worn out or
