7
NOTE:
Anchoring the turnkey kitchen
requires drilling through the wall and/or the
floor. Proper spacer placement is essential
for a secure installation. If you are unsure
how to install spacers correctly, professional
installation is recommended.
Figure 2
Follow these steps to properly attach the
faucet to the sink:
1. Remove the mounting hardware
and set aside.
2. Position faucet body to the sink
hole.
3. Secure the mounting hardware
till snug. (Figure 1)
4. Attach the spray hose and install
counterweight on spray hose.
(Figure 2)
5. Connect waterlines and tighten
with a wrench. If you are
unfamiliar with plumbing, we
recommend seeking
professional help for this step.
6. Detach the spray head from the
hose to flush out debris. Hold the
tip of the spray hose, turn on the
faucet, and let the water run for 60
seconds.
7. Check for leaks, tighten if necessary.
Anchoring the Turnkey Kitchen
After installing the spacers, anchor the turnkey
kitchen with the following methods:
1.
Use the pre-drilled holes in the metal
frame located on the back of the
cabinetry with the appropriate spacer
for secure attachment.
2.
Alternatively, drill through the back
cabinets to anchor the unit.
Both methods provide added support
and security for the installation.
Removing Support Brace
(If applicable to your turnkey kitchen)
Only remove the support brace after properly installing the
unit.
1. Locate the brace at the front of the cavity.
2. Remove the screws on each side of the brace.
3. Discard the brace.
Refrigerator
(CT661WBIIF, CT661WBIIFADA, ASDG2411PNR,
SDHG2443PNR, AL57GPNR, CL24BV1)
1. Connect the Refrigerator:
Before pushing the refrigerator in place, connect it
to the power source.
2. Adjust the Legs:
Make sure the refrigerator is level by adjusting its
legs if necessary.
Raise the refrigerator legs to
decrease the gap between the counter for a cleaner
more cohesive look.
3. Consult the Refrigerator’s Manual:
Refer to the refrigerator’s user manual for
additional installation instructions and power
requirements.
Cooktop
(SINC2B115)
Consult the Cooktop’s Manual:
Refer to the cooktop’s user manual for additional
installation instructions and power requirements.
Adhering the Backsplash
(Optional)
Consider attaching the backsplash before anchoring
the kitchen, depending on your installation
preferences.
1. Apply silicone along the edge of the
countertop.
2. Position the backsplash.
3. Use temporary braces to hold the backsplash in
place until the silicone cures.
Figure 1
