18
INSTALLATION INSTRUCTION
5.
6.
Tighten the strain relief screws.
Insert the tab of the terminal block cover into your dryer’s rear panel slot. Secure
the cover with a screw.
Ring-type terminals are recommended. If using strap terminals, make sure
they are tightened.
WARNING
U.S. Models:
Risk Of Electric Shock - All U.S. models are produced for a 3-WIRE
SYSTEM CONNECTION.
The dryer frame is grounded to the neutral conductor at the terminal block.
A 4-WIRE SYSTEM CONNECTION is required for new or remodeled
construction,mobile homes, or if local codes do not permit grounding through
neutral conductor.
If the 4-wire system is used, the dryer frame cannot be grounded to the neutral
conductor at the terminal block. Refer to the “Electric requirements”
section on page 14 for 3-WIRE or 4-WIRE SYSTEM CONNECTIONS.
Remove the terminal block cover plate.
Insert the power cord with a UL-listed strain relief through the hose provided
in the cabinet near the terminal block.
- A strain relief must be used.
Do not loosen the nuts already installed on the terminal block. Be sure they
are tight.
Use a 3/8" (1cm) deep well socket.
WARNING
STEP 3 Level the dryer
To ensure that the dryer provides the optimal drying performance, it must be leveled.
To minimize vibration, noise, and unwanted movement, the floor must be a perfectly
level, solid surface.
- Adjust the leveling feet only as much as necessary to level the dryer. Extending the
leveling feet more than necessary can cause the dryer to vibrate.
4-Wire system instructions:
IMPORTANT: Ring-type terminals are recommended. If using strap terminals, make sure they are tightened.
A Center terminal block screw
B External ground connector
C Green or bare copper wire of the
power cord
D Neutral grounding wire (White)
E Neutral wire (white or center wire)
F 3/4" (1.9cm) UL-listed strain relief
A
B
C
D
E
F
White
Black
Red
Green
