subzero.com | 19
Overlay Panel Dimensions
MODEL CL3650UFD(ID)
REFRIGERATOR (2 PANELS) W H
Overlay Panel 17⁄" (454) 50⁄" (1286)
Spacer Panel 17" (432) 49⁄" (1265)
Backer Panel 17⁄" (448) 50⁄" (1281)
FREEZER W H
Overlay Panel 36" (914) 20" (508)
Spacer Panel 35⁄" (892) 19⁄" (484)
Backer Panel 35⁄" (908) 19⁄" (500)
GRILLE W H
Overlay Panel 36" (914) 7⁄" (197)*
Spacer Panel 35⁄"
(892) 6⁄" (173)
Backer Panel 35⁄" (908) 7⁄" (189)
MODEL CL4250UFD(ID)
REFRIGERATOR (2 PANELS) W H
Overlay Panel 20⁄" (530) 50⁄" (1286)
Spacer Panel 20" (508) 49⁄" (1265)
Backer Panel 20⁄" (524) 50⁄" (1281)
FREEZER W H
Overlay Panel 42" (1067) 20" (508)
Spacer Panel 41⁄" (1045) 19⁄" (484)
Backer Panel 41⁄" (1060) 19⁄" (500)
GRILLE W H
Overlay Panel 42" (1067) 7⁄" (197)*
Spacer Panel 41⁄" (1045) 6⁄" (173)
Backer Panel 41⁄" (1060) 7⁄" (189)
MODEL CL4850UFD(ID)
REFRIGERATOR (2 PANELS) W H
Overlay Panel 23⁄" (606) 50⁄" (1286)
Spacer Panel 23" (584) 49⁄" (1265)
Backer Panel 23⁄" (600) 50⁄" (1281)
FREEZER W H
Overlay Panel 48" (1219) 20" (508)
Spacer Panel 47⁄" (1197) 19⁄" (484)
Backer Panel 47⁄" (1213) 19⁄" (500)
GRILLE W H
Overlay Panel 48" (1219) 7⁄" (197)*
Spacer Panel 47⁄" (1197) 6⁄" (173)
Backer Panel 47⁄" (1213) 7⁄" (189)
*Panel height may be increased by ⁄" (11) to hide upper main frame.
MODEL CL4250S(ID), CL4250SD
REFRIGERATOR W H
Overlay Panel 25⁄" (637) 71⁄" (1810)
Spacer Panel 24⁄" (614) 70⁄" (1789)
Backer Panel 24⁄" (630) 71⁄" (1805)
FREEZER W H
Overlay Panel 16⁄" (424) 71⁄" (1810)
Spacer Panel 15⁄" (402) 70⁄" (1789)
Backer Panel 16⁄" (418) 71⁄" (1805)
GRILLE W H
Overlay Panel 42" (1067) 7⁄" (197)*
Spacer Panel 41⁄"
(1045) 6⁄" (173)
Backer Panel 41⁄" (1060) 7⁄" (189)
CL4250SD W H
Dispenser Cutout 6⁄" (162) 13" (330)
A B
Cutout Location 2⁄" (54) 32⁄" (832)
MODEL CL4850S(ID), CL4850SD
REFRIGERATOR W H
Overlay Panel 28⁄" (730) 71⁄" (1810)
Spacer Panel 27⁄" (708) 70⁄" (1789)
Backer Panel 28⁄" (724) 71⁄" (1805)
FREEZER W H
Overlay Panel 19" (483) 71⁄" (1810)
Spacer Panel 18⁄" (460) 70⁄" (1789)
Backer Panel 18⁄" (476) 71⁄" (1805)
GRILLE W H
Overlay Panel 48" (1219) 7⁄" (197)*
Spacer Panel 47⁄" (1197) 6⁄" (173)
Backer Panel 47⁄" (1213) 7⁄" (189)
CL4850SD W H
Dispenser Cutout 6⁄" (162) 13" (330)
A B
Cutout Location 2⁄" (54) 32⁄" (832)
Classic Series Refrigeration
