subzero.com | 7
84"
(2134)
FLUSH
INSET
HEIGHT
1
/4"
(6)
26
3
/16"
(665)
FLUSH
INSET
DEPTH
2
3
/
16
"
(56)
FRONT VIEW
SIDE VIE
W
TOP VIEW
FINISHED
CLEATS
1
1
/4"
(32)
W
FLUSH INSET WIDTH
NOTE: 3
1
/2" (89) finished returns and shaded areas will be visible and should be finished to match cabinetry.
Shaded line represents profile of unit wit
h
3
/4" (19) panel.
5
11
/16"
(145)
FINISHED
RETURN
FILLER
FRAMED
CABINETRY
W
CLEAT
3
/4" (19)
TYPICAL
3
1
/2"
(89)
5
11
/
16
"
(145)
FINISHED
RETURN
FRAMELESS
CABINETRY
W
3
1
/2"
(89)
CLEAT
3
/
4
"
(19)
TYPICAL
Dimensions assume a ⁄" (19) panel thickness. A dual instal-
lation kit is required for this installation.
DUAL FLUSH INSET WIDTH W
Two 30" Models 62⁄" (1581)
30" and 36" Models 68⁄" (1734)
Two 36" Models 74⁄" (1886)
Site Preparation
Opening Dimensions
DUAL FLUSH INSET INSTALLATION
