CASE DESIGN & FIELD SERVICE PARTS LIST, CONT’D: CASE REAR VIEW
2. Case Rear View
• Model NR3640HSSV with rear sliding doors is illustrated below.
• Solid back units differ from unit shown.
FIELD SERVICE PARTS LIST: CASE REAR VIEW
P/N COMPONENT NAME AMT P/N COMPONENT NAME AMT
6 REAR UPPER PANEL 1 9 REAR-LEFT SIDE PANEL 1
7 REAR-RIGHT SIDE PANEL 1
8 REAR LOWER PANEL 1
Model NR3640HSSV Free-Standing
Unit (Shown) May Not Exactly Reflect
Every Feature or Option of Your
Particular Case.
6
7
9
8
