INSTALLATION: TOE-KICK REMOVAL / DISCONNECTING CASE FROM PALLET

Pallet

Rubber Shipping

Blocks, (Typ.)

Shipping Bracket

1. Remove Front Toe-Kick From Case

• To prevent damage to case, remove front

toe-kick from case before removing from

pallet.

• Toe-kick is held in place by magnets only.

No screw removal is required.

• Place front toe-kick in secure location

while removing case from pallet.

Front Toe-Kick

2. Disconnect Case From Pallet

• Remove screws from shipping brackets.

Remove and discard shipping brackets

from pallet.

• Place J-bar/pry under base frame.

Raise case up from pallet to take weight

off casters.

• With case raised, lower casters all the

way down against pallet (see next step

for detailed instructions on lowering or

raising casters).

• Remove rubber shipping blocks.
