FREQ. INSTRUCTIONS

Quarterly

Tub Area:

• Caution! Turn off power to case. Allow case to cool for 45 minutes before proceeding.

• Open front doors to access decking.

• Remove sub-deck and deck pans. See CASE DESIGN, CONT’D: TUB AREA / HEATER /

OPTIONAL POWERED HUMIDIFICATION SYSTEM ACCESS section in manual for

instructions and illustrations.

• Wipe down tub, axial fans and deck pan.

• Thoroughly clean humidification system to remove residue and grime. Use disinfectant/germicide

in spray bottle to kill bacteria. Rinse with clean water in spray bottle.

• Return subdeck and deck pans to case.

• Restore power to case.

Quarterly Cleaning Optional Powered & Passive Humidification Systems

Preparation:

• Caution! Turn off power to case. Allow case to cool for 45 minutes before proceeding.

• Open front doors to access decking.

• Remove sub-deck and deck pans. See See CASE DESIGN, CONT’D: TUB AREA / HEATER /

OPTIONAL POWERED HUMIDIFICATION SYSTEM ACCESS section in manual for

instructions and illustrations.

• Use wet/dry vacuum to empty the humidification system of water.

Humidification System:

• For Passive Humidification Systems only, remove stainless steel cover (two pieces) from case.

Submerse in warm, soapy water and clean thoroughly with soft-bristled brush. Rinse. Dry. Return

to case AFTER the humidification system cleaning process has been completed.

• For cleaning humidification system, use a mixture of 75% water / 25% unflavored white vinegar to

fill the rear water inlet funnel.

• Set control panel’s HUMIDITY setting at its highest (9) and allow unit to run for 30 minutes.

• Use a soft-bristled brush to dislodge the lime/calcium accumulation from the humidification system.

• Turn off main power switch and allow the unit to cool.

• Use wet/dry vacuum to remove the de-liming solution from the humidification system.

• Use a clean sponge and/or clean rags to sop up any remaining de-liming solution.

• Then, using clean, pure water, fill and drain the humidification system until any remaining water

and/or white vinegar solution is rinsed through and the water discharge is clean.

Water Inlet Funnel Hose and Hose From Humidification System Pan To Overflow:

• Remove the water inlet funnel (from case rear); disconnect from hose. Submerse in warm, soapy

water. Clean with soft-bristled brush. Rinse. Dry. Return it to case rear. Securely reconnect hose

to water inlet funnel.

• Check that hose to BOTH water inlet funnel and humidification system is supple and in good

condition; If cracking or showing signs of fatigue, contact Structural Concepts for

replacement.

• Turn power back on and fill the water inlet funnel back up (as described in the CASE DESIGN,

CONT’D: POWERED HUMIDIFICATION SYSTEM / WATER CAPACITY/TYPE section of this

manual).

WARNING! TURN OFF CASE BEFORE PERFORMING PREVENTIVE MAINTENANCE!

PREVENTIVE MAINTENANCE (TO BE PERFORMED BY TRAINED SERVICE PROVIDER)
