21
CASE DESIGN, CONT’D: CONDENSER PACKAGE (SELF-CONTAINED UNITS ONLY)
Refrigeration
U-Tubes
Filter Dryer
Electrical
Starter Unit
Condenser Coil
Housing
Condenser Coil
Fans & Motors
Overflow
Condensate Pan
(With Electric Coil)
Hot Gas Loop
Condensate Pan
Sight Glass
Compressor
12. Condenser Package (Self-Contained Units)
Assembly/disassembly and servicing to be performed by licensed refrigeration contractor.
Condensate Package Configuration
• Illustration shown is from model NR3658RRSSV. Your unit’s component layout may slightly vary.
Controller DC
Driver
Evaporator
Section
Drain PVC
Optional Clean Sweep®
Condenser Coil
Cleaning System
