Reveal® User Manual 11

Shelf and Deck Load Limits

The chart below are the load limits for the shelves and decks. All weights below are for a uniformly distributed load. All

values in pounds.

MODEL

MAX 10”D SHELF

LOAD

MAX 12”D SHELF

LOAD

MAX 14”D SHELF

LOAD

MAX 16” & 18”D

SHELF LOAD

MAX DECK

PAN LOAD

NE3613RSV

NA NA NA NA 132

NE3620RSV NA NA NA 110 132

NE3627RSV NA NA 88 110 132

NE3635RSV

66 66 88 NA 132

NE4813RSV

NA NA NA NA 184

NE4820RSV

NA NA NA 154 184

NE4827RSV

NA NA 123 154 184

NE4835RSV

92 92 123 NA 184

NE6020RSV

NA NA NA 198 237

NE6027RSV

NA NA 158 198 237

NE6035RSV

118 118 158 NA 237

NE7220RSV

NA NA NA 242 277

NE7227RSV

NA NA 193 242 277

NE7235RSV

145 145 193 NA 277

NR3633RSV

NA NA NA NA 132

NR3640RSV

NA NA NA 110 132

NR3647RSV

NA NA 88 110 132

NR3655RSV

66 66 88 NA 132

NR4833RSV

NA NA NA NA 184

NR4840RSV

NA NA NA 154 184

NR4847RSV

NA NA 123 154 184

NR4855RSV

92 92 123 NA 184

NR6040RSV

NA NA NA 198 237

NR6047RSV

NA NA 158 198 237

NR6055RSV

118 118 158 NA 237

NR7240RSV

NA NA NA 242 277

NR7247RSV

NA NA 193 242 277

NR7255RSV

145 145 193 NA 277
