Fusion® User Manual 6

Oasis® B(L)24 User Manual 6

Installation: Case Removal From Skid

Remove Lower Front and End Panel From Case:

• To prevent damage to the case, remove the lower front

panel and the lower side panel from the case before

removing it from the pallet.

• The lower front and side panel is held in place by

magnets only. No screw removal is required.

• Place the lower front and lower side panel in a secure

location while removing the case from the pallet.

Remove Lower Rear and End Panel From Case:

• Remove the lower rear panel and the lower side panel

from the case before removing it from the pallet.

• The lower rear and side panel is held in place by

magnets only. No screw removal is required.

• Place the lower rear and lower side panel in a secure

location while removing the case from the pallet.

Disconnect Case From Pallet:

• Remove screws from shipping brackets. Remove and

discard shipping brackets from the pallet.

• Raise the leveler all the way up to engage the casters.

Lower Front Panel

Lower Rear Panel

Shipping Bracket

Oasis® MI4(L)RF User Manual 6

Lower End

Panel

Lower End

Panel
