Fusion® User Manual 13Oasis® MI4(L)RF User Manual 13
Lower Rear Panel Removal
Servicing of refrigeration components is to be done by a licensed refrigeration contractor.
• Remove lower rear panel by grabbing the bottom of the panel and pull forward to release magnets.
• Carefully slide condenser package pan out from under case to access various components.
• For reassembly, reverse the order items were removed.
Front Panel
Lower Rear Panel
