Fusion® User Manual 8Oasis® User Manual 8

Installation: Start Up

Plug Case In/Turn On Main Power Switch:

• Do not use an extension cord with this case.

• Do not operate this equipment with a damaged cord,

plug, or outlet.

• Ensure that the main power switch is off. (Note that the

FSI660, FSI860, FSE660, and FSC660 have two power

switches.)

• Plug the cord into a certied 240V electrical outlet with

ground.

• Turn the main power switch/switches on.

• Coil fans should turn on.

• From inside of the case, check for discharge air from

front, side, and end honeycomb, (if applicable), to

conrm that the fans are functioning properly.

• When the case is in a start-up mode or has been idle for

a long period of time, the case may require 75 minutes

running time to pull down the temperature.

• Turn lights on.

• Light switch is located on the ceiling of merchandising

area.

• The lights should come on at the same time.

• Always maintain front and rear airow clearance of four

inches.

• Obstruction or restriction of air can void warranty.

• Note: Case temperature setting is determined by case

size. Temperature is controlled by a thermostat.

Light Switch

Main Power Switch

Drain Tubes

Check All Drain Connections:

• A series of drain tubes connect the tub to multiple

condensate pans.

• Ensure all drain tubes are connected and sealed.

• Loose drain tubes can cause water to leak. If leak is

detected check all drain tube connections.
