Fusion® User Manual 6

Oasis® B(L)24 User Manual 6

Installation: Case Removal From Skid

Remove Lower Panels From Case:

• To prevent damage to the case, remove the lower front

and panel from the case before removing it from the

pallet.

• Panels are secured by a set of hooks and magnets.

• Lift panels up to unhook and out to release magnets

• Place the panels in a secure location while removing the

case from the pallet.

Remove Lower Side Panel From Case:

• Panels are secured by a set of hooks and magnets.

• Lift panels up to unhook and out to release magnets

• Place the panels in a secure location while removing the

case from the pallet.

• Verify power cord will not interfere with casters or get

caught on the pallet during removal.

Disconnect Case From Pallet:

• Remove screws from shipping brackets. Remove and

discard shipping brackets from the pallet.

• Raise the levelers all the way up to engage the casters.

Lower Panel

Lower Side Panels

Shipping Bracket

Oasis® User Manual 6
