CONDITION TROUBLESHOOTING

Fan Emits Excessive

Noise

Check that the case is aligned, level and plumb.

Check evaporator fan for cleanliness.

Unplug/power off fan motor. Check motor shaft for bearing wear.

Check that fan motor is securely mounted in brackets.

Verify that fan blades are securely mounted to fan motor.

Check that nothing is preventing blade rotation.

Check that the fan shroud is properly secured.

Fan Is Not Working Check that the MAIN power switch is on.

Check that fan connector is securely plugged in at fan shroud.

Check that fan connector is securely plugged in near close-off.

Check for foreign material obstructing fan performance.

Check that fan blade freely rotates within fan shrouds

Check that power is going to fans

Check that fan wiring is connected on terminal blocks.

Programmable

Controller Display

Is Blank

Check that the MAIN power switch is on.

Check circuit breaker box for tripped circuits.

Programmable

Controller Display Is

Flashing

See your case’s serial label for your model’s specified settings. See SERIAL

LABEL LOCATION & INFORMATION LISTED / TECH INFO & SERVICE for

label location, etc.

System Not Operating Check that the utility power is on.

Check that the MAIN power switch is on.

Check the circuit breaker box for tripped circuits.

Case Lights Are Not

Working

Check that light switch is in the on position.

Check that ALL of the light cords and plugs are properly connected. See LED

LIGHT FIXTURES section in this manual for specifics.

Service Technicians Only: Check voltage at LED drivers. If voltage is entering

but not exiting, LED driver may be faulty.

TROUBLESHOOTING (TO BE PERFORMED BY TRAINED SERVICE PROVIDER ONLY) - PAGE 2 of 3
