STARTUP, CONTINUED - CONTROL PANEL EXPLODED VIEW (MODEL B2432H ONLY)
Model B2432H - Control Panel Exploded View
1. Field Access Box
• Field access box is at lower-left of control panel.
2. Main Power / Lights
• Main power switch and lights switch are at right
of control panel (as shown below).
3. Shelves and Deck Heater Controls
• Heater controls to shelves and deck are on
control panel.
• See Carel® Controller information in this manual
for specifics.
Shelf One
Shelf Three
Shelf Two
Shelf Four
(Optional)
Deck
