TROUBLESHOOTING (TO BE PERFORMED BY STORE PERSONNEL)

CONDITION TROUBLESHOOTING

Case Lights

Not Working

Check that light switch is in the ON position.

 See illustration below for light switch location at case rear.

If case is not hard-wired, check that power cord is properly connected to wall outlet.

Check that ALL of the light plugs are properly connected to the LED light.

 Plug must be inserted ALL THE WAY into the LED light orifice (with no gap).

 See illustrations below-left.

Power may not be reaching the case.

 Contact store management to have trained service provider perform troubleshooting.

 Troubleshooting to be performed by trained service providers only is on next page.

If case light still do not come on, it may need to be replaced.

 Contact Structural Concepts’ Technical Service Department for replacement light

(see TECHNICAL SERVICE section of this manual for contact information).

 To replace, disconnect plug from existing LED light. Disconnect LED light from its

brackets. Replace with new LED light. Insert plug ALL THE WAY into LED light orifice.

No Gap

Gap

LED Light

Plug

Light

Switch
