TROUBLESHOOTING (TO BE PERFORMED BY TRAINED SERVICE PROVIDERS)

CONDITION TROUBLESHOOTING

Water On Floor Check that the drain trap is free of debris.

Check store conditions.

• For Type 1 Conditions (most cases): ambient conditions are to be at 55%

maximum humidity / 75 °F.

• For Type 2 Conditions: ambient conditions are to be at 60% maximum

humidity / 80 °F.

Fan Emits Excessive

Noise

Check that the case is aligned, level and plumb.

Check axial fans (and/or wire bracket covers) for cleanliness.

Check that nothing is preventing blade rotation.

Check that the fan shroud is properly secured.

Fans Are Not Working Note: Fan locations vary, depending upon your particular model.

For location of fans in tub area, see START-UP & OPERATION -

REFRIGERATED UPPER SECTION in this manual.

Check that fans are properly connected.

Check for foreign material obstructing fan performance.

Check that fan blades freely rotate within fan shrouds

Check that power is going to fans

Check that fan wiring is connected on terminal blocks.

System Is Not Operating Check that the utility power is on.

Check the circuit breaker box for tripped circuits.

Case Is Not Holding

Temperature

Axial fan blades may need to be cleaned.

• Disconnect power to case before proceeding.

• For location of fans in tub area, see START-UP & OPERATION -

REFRIGERATED UPPER SECTION in manual.

• For location of fans in side bracketry, see next page in manual.

• To clean wire fan guards, remove screws holding fan guards in place.

Submerse in warm, soapy water. Rinse. Dry with clean cloth or paper towel.

• To clean axial fan blades, remove fan guards. Wipe down fan blades with

soft cloth dipped in warm, soapy water. Wipe off residue with clean cloth or

paper towel.

• Return wire fan guards to case. Tighten screws securely. Reconnect power

to case.

Determine if temperature controller settings are properly set. See your case’s

serial label for your model’s specified settings. See SERIAL LABEL

LOCATION & INFORMATION LISTED / TECH INFO & SERVICE section in

manual for label location.
