11
ELECTRICAL OVERVIEW: FIELD ACCESS / DRIVERS / FIELD SENSOR / T-STRIP
1. Electrical Overview: Field Access Box / Drivers / Field Sensor Box / Terminal Strip
• Caution! Only certified electricians are to perform electrical connectivity duties.
• Remove front panels (via hook/magnet method) to access field access box (see previous page).
• Remove screws at front of field access boxes allows access to drivers and other electrical components.
Model FB8SS-6R Is Shown.
It May Not Reflect Every
Feature Or Option of Your
Particular Case.
