REFRIGERATED REAR SECTION WITH HINGED DOOR

1. General Layout

• Refrigerated wells, compartment and drawer,

sneeze guard, Sanalite® rear ledge, drain valve,

thermometers, etc., are shown below.

2. Cleaning Refrigeration Area

• Refrigeration area must be cleaned regularly.

• See cleaning schedule in manual for specifics.

3. Thermometers

• Upper digital thermometer displays temperatures

of the refrigerated upper section (with pans and

dividers).

• Lower digital thermometer displays temperatures

of the rear refrigerated section (either behind

sliding doors or hinged door).

• Thermometers are for monitoring internal air

temperature only (not actual food temperature).

• Use probe thermometers to determine actual

product temperatures.

• See illustration below for general locations.

Upper Thermometer

For Refrigerated

Wells Section

Rear Hinged Door To

Refrigerated Section

Refrigerated

Well

Sanalite® Rear

Ledge (Typ.)

Glass Sneeze

Guard (Typ.)

Lower Thermometer

For Rear Refrigerated

Section (Door)

--- Model FB2S-1R Shown Above ---

Model FB2S-1R Is Shown In This

Illustration. It May Not Reflect

Every Feature Or Option of

Your Particular Case.
