Fusion® User Manual 7Fusion® MD User Manual 7

Installation: Case Removal From Skid

Levelers:

• There are levelers on each corner of the case.

• Raise levelers to their highest position to engage the

casters.

Carefully Remove Case From Pallet:

• Check that levelers are fully raised.

• Caution! 4 people are required for this task!

• Carefully lower to the oor (using a ramp if available).

• Slide pallet from under case as required.

• Maintain support of the case at all times, or the center of

gravity may cause the case to fall.

• See the illustration at right.

Levelers:

• After the case is at the desired position, lower the levelers

to secure the case in position. Check that the case is

level.

• Adjust height as needed.

Levelers

Ramp

Support

case while

moving

Levelers
