CLEANING SCHEDULE TO BE PERFORMED BY STORE PERSONNEL* - PAGE 2 of 2

*This Service Is To Be Performed By Trained Service Providers Only

FREQ. INSTRUCTIONS

Quarterly

Under Case Cleaning (Remote Units): Caution! Do not clean flooring in a manner that

causes dust to be circulated into the air! Remove rear toe-kick and clean underside of case

with broom or vacuum with extended hose. Replace rear toe-kick to case.

Under Case Cleaning (Self-Contained Units): Caution! Do not clean flooring in a manner

that causes dust to be circulated into the air! Remove rear grille. Remove condenser package

shipment screws. Carefully slide condenser package out from under case. Remove toe-kick.

Clean underside of case with broom or vacuum with extended hose. Carefully slide condenser

package back under case. Return rear grille and front toe-kick to case.

Quarterly

Condenser Coil Cleaning: Remove rear condenser grille. Using an industrial strength

vacuum with bristled brush, clean the dust and dirt that collects on the condenser coil.

Caution! Be careful not to damage the fins on the coil.

Quarterly

*Clean Condensing Unit (including Evaporator Pan):

Warning! Hot gas loop coil may be hot. Allow to cool 15-minutes before cleaning.

Note: See CONDENSER PACKAGE (SELF-CONTAINED UNITS ONLY) section in this

manual for illustration.

1. Turn off refrigeration main power switch (or disconnect case from power source).

2. Remove rear grille (by lifting up and off). Remove shipping screws (if still attached).

3. Slide condenser package out from case rear.

4. Thoroughly clean evaporator pan area with de-scaling solution, such as CLR®. Rinse

thoroughly.

5. Use clean towel dipped in soap and water solution to wipe down fan motor, fan blades,

refrigeration lines, cords, knobs, sight glass, filter dryer, receiver, connectors, etc.

6. Wipe dry.

7. Slide condenser package back under case. There is no need to reattach shipping

screws (if any).

8. Replace rear grille.

9. Turn power back on (or reconnect power) to merchandiser.

Quarterly *Honeycomb: See MAINTENANCE FUNDAMENTALS - HONEYCOMB AIR DIFFUSERS

section in this manual for removal, replacement and cleaning instructions.

* UNLESS SPECIFIED OTHERWISE
