START-UP / LIGHTING / CASE TEMP. / PROGRAMMABLE CONTROLLERS / OPERATION

1. Merchandiser Start-Up

• Case must be field wired.

• When power is supplied, throw main power

switch at case rear-right and case will power-up.

• See illustration below-right.

2. Lighting

• Overhead light switch is at case rear, right

side.

• See illustration below-right.

3. Case Temperature

• Well temperature is dependent upon both the

waterless well temperature and the overhead

ceramic heater temperatures.

• Preheat case to 170 °F on case temperature

dial (photo shown below-left) before placing

food into case.

• Caution: Case Temperature dial reflects internal

case temperature ONLY (not product temperature).

Use a food probe to determine ACTUAL product

temperature!

4. Product Heating Guidelines / Programmable

Controllers

• Well and overhead ceramic heaters are controlled by

Programmable Controllers.

• These controllers are located on rear wireway cover

(as shown in illustration below-right).

• Programmable controllers are pre-set at the factory to

heat both overhead and well at proper temperatures.

Modifications to these settings should be rare.

• Should programmable controllers need to be revised,

see PROGRAMMABLE CONTROLLER

INFORMATION section in this User Manual for

additional information.

Case

Temperature

Dial
