OPERATION: MODEL GMGX4 BLOWER COIL WEDGE UNIT ONLY - PAGE 1 of 2

1. Flat Glass / Shelf / Front Panel / Drain

• Upper gravity coil is NOT available on this model.

• Caution! Due to its design, only ONE flat glass

piece may be raised at a time.

• Shelf is removable (but not adjustable).

• Front panel is removable (no screw removal req’d).

• Underside of case (remote unit shown) displays

drain/P-trap and refrigeration lines.

Ice Trays

With Handles

Model GMGX4

Shown. Your Case

May Differ

Removable Front

Panel (No Screw

Removal Required)

Adjustable Shelf

Shields For

LED Lights

Flat Glass (Typ.)

Rear Hinged

Door

LED Lights

Drain/P-Trap

Frame Support Rail (Typ.)

Flat

Glass

Refrigeration Lines

Adjustable

Shelf

2. Humidification Feature (Optional)

• Optional humidification feature prevents the

“drying effect” of refrigeration allows case to

retain proper humidity levels without ‘wetting’

the product.

• Ultrasonic nozzles produces a fine vapor fog

(“mist”) that permeates product in the case .

Upper

Clamshell
