PREVENTIVE MAINTENANCE - TO BE PERFORMED BY TRAINED SERVICE PROVIDERS ONLY

PREVENTIVE

MAINTENANCE

FREQ. INSTRUCTIONS

Case Exterior Quarterly Condensing Coil:

• Remove rear grille to access area. Simply lift up and off.

• Roll/slide out condenser package. Note: At initial slide-out, it may be

necessary to remove two (2) compressor pan shipment screws to slide it

out from under case.

• Warning! Coil fins are sharp. Handle with care!

• Caution! Airborne dust can contaminate food! Use wet rags to cover

area where air pressure is blowing.

• Use air pressure or industrial strength vacuum; clean dust and dirt that

may collect on condenser coil.

• Slide/roll condensing package back under case.

• Return rear grille to case.

Quarterly Under Case Cleaning:

Once refrigeration package is clear of unit, vacuum under case to remove all

dust and dirt that collects under case.

Quarterly Rear Sliding Doors:

• Rear sliding doors can become loose, sloppy or dislodge from their door

tracks. Doors could eventually FALL OUT of the door frames and into (or

out of) the case causing damage or injury.

• Bottom door guides may have become worn and need to be replaced.

• Contact Structural Concepts’ Technical Service for guidance and/or

replacement parts information. See last page of manual for contact info.

Case Interior Quarterly Tub, Coil, Drain, Evaporator Fans, Brackets:

• Remove decking.

• Use vacuum to clean entire area.

• After vacuuming, clean area with warm water, clean cloth, and mild soap

solution.

• Remove any debris that may clog drain.

Quarterly Honeycomb: Check honeycomb air diffuser to determine whether it is dirty. If

dirty, remove from case. Clean with mild detergent. Rinse with high-pressure

sprayer. Dry. Return to case.

Quarterly Refrigeration Package/Compressor Area (Self-Contained Units Only):

Caution! Be certain to disconnect power from case before cleaning

refrigeration package!

• Warning! Overflow condensate pan Is HOT! Disconnect power from case

and allow to cool before cleaning evaporator pan!

• Slide/roll compressor package out from under case.

• Use a scrub-brush and a de-scaling solution such as CLR® (to prevent

corrosion, lime and rust). Follow instructions as to proper dilution, safety

precautions and scrubbing method.

• After thoroughly cleaning pan with scrub-brush and solution, rinse

thoroughly with clean water (in spray bottle) and wipe dry with sponge or

paper towel.

• Use moist cloth to wipe off dust & debris that collects on various parts

(fans, sight glass, overflow pan, etc.).

• Slide refrigeration assembly back under case.

• Replace front panel and lower grille via hooks (no screws required).

WARNING! TURN OFF CASE BEFORE PERFORMING PREVENTIVE MAINTENANCE!
