START-UP AND OPERATION

Merchandiser Start-Up

• Unit will energize when properly field wired.

• Evaporator coil fans will automatically turn on.

From the front of the case, lift glass and remove

the decking; check to see that the coil fans are all

functioning properly.

• Lights switch is accessible at case front-left, near

upright. See illustration below.

• Turn light switch on. All lights should come on at

the same time. First time lighting may require a

short warm up-period for the bulbs.

• Slightly dim or a flickering of new bulbs is normal.

Digital Thermometer

• If lights do not turn on, check all raceway

plugs. The lighting is wired in series so all

lights must be plugged in or receptacles

capped in order for the case to light.

• Refrigeration section has been tested to

maintain temperature at or below 5 °Celsius /

41 °Fahrenheit.

• Note: Thermometers provided with equipment

reflect internal air temperature only (not actual

food temperature). Use probe thermometers to

determine actual product temperatures.

41°F

Light

Switch

Light

Switch

Spirit-Filled

Thermometer

Spirit-Filled

Thermometer

41°F

Digital

Thermometer

Viewable at

Case Rear
