TROUBLESHOOTING - TO BE PERFORMED BY STORE PERSONNEL (UNLESS NOTED OTHERWISE)

CONDITION TROUBLESHOOTING

Ice Is Forming on

Evaporator Coils

Perform extended manual defrost weekly. See CLEANING SCHEDULE - TO BE

PERFORMED BY STORE PERSONNEL section in manual for additional infor-

mation.

Product Is Drying

Out

Trained Service Providers Only: Check the relative humidity in the store.

Water Is On The

Floor

Trained Service Providers Only: Check that the drain trap is free of debris.

Check that the drain hose is correctly positioned over hot gas condensate pan.

Trained Service Providers Only: Check store conditions.

 For NSF® Type 1 Conditions (most cases): ambient conditions are to be at 55%

max. humidity / 75 °F.

 For NSF® Type 2 Conditions: ambient conditions are to be at 55% maximum

humidity / 80 °F.

Fan Emits

Excessive Noise

Trained Service Providers Only: Check that the case is aligned, level and plumb.

Trained Service Providers Only: Check evaporator fan for cleanliness.

Trained Service Providers Only: Unplug/power off fan motors. Check motor shaft for

bearing wear.

Trained Service Providers Only: Check that fan motors are securely mounted in

brackets.

Trained Service Providers Only: Verify that fan blades are securely mounted to fan

motor.

Trained Service Providers Only: Check that nothing is preventing blade rotation.

Trained Service Providers Only: Check that the fan shroud is properly secured.

Fans Not Working Check that the MAIN power switch is on.

Trained Service Providers Only: Check that fans are plugged in at the fan shroud.

Trained Service Providers Only: Check for foreign material obstructing fan

performance.

Trained Service Providers Only: Check that fan blades freely rotate within fan

shrouds.

Trained Service Providers Only: Check that power is going to fans.

Trained Service Providers Only: Check that fan wiring is connected on terminal blocks

Digital Control

Display Is Blank

Check that the MAIN power switch is on.

Trained Service Providers Only: Check the circuit breaker box for tripped circuits.

System Not

Operating

Trained Service Providers Only: Check that the utility power is on.

Check that the MAIN power switch is on.

Trained Service Providers Only: Check the circuit breaker box for tripped circuits.
