12
ADJUSTABLE SCALE STAND (GLDSS10R.5255) / REAR OUTLETS (GLDSS443R.5951)
Thumbscrew (For
Adjustable Scale Stand)
Locking Pad (For
Thumbscrew Pressure)
Adjustable
Scale Stand
Adjustable Scale Stand
• View shown below is illustrated with optional rear
pushup work counter.
• Entire adjustable scale stand may be removed
from case for cleaning purposes. See
CLEANING SCHEDULE (TO BE PERFORMED
Support Bracket
(For Adjustable
Scale Stand)
Outer Retaining Screws (For
Adjustable Scale Stand) Typ.
Inner Retaining Screws (For
Adjustable Scale Stand) Typ.
Model
GLDSS443R.5951
BY STORE PERSONNEL) for instruction on
removing scale stand and cleaning specifics.
• If adjustable scale stand material is butcher block,
see BUTCHER BLOCK CLEANING
INSTRUCTIONS section in this manual.
Rear Outlet
Rear Outlet
Model
GLDSS10R.5255
