CONDITION TROUBLESHOOTING

Case Not Lining

See INSTALLATION section in this manual for instructions on properly aligning case

(alongside other cases) and adjusting levelers.

Water Is On The

Floor

Caution! Water on flooring can cause much damage! Until cause is determined

(and repaired), following these procedures:

• Use wet-dry vacuum (or mop & bucket) to remove standing water.

• Use ‘catch pans’ for water to drain into. Swap out regularly until case has

completely drained.

Note: See Drain, Hose and Bracket Placement Illustrations sheet in this manual for

views of different condensate systems used in display cases.

Check that the drain trap is free of debris.

Check that the drain hose is correctly positioned over condensate pan (or floor drain,

for remote units).

Check store conditions.

• To prevent condensation in NSF/ANSI Type I environments, maximum conditions

are to be 55% relative humidity / 75° Fahrenheit.

• For NSF/ANSI Type II environments, maximum conditions are to be 55% relative

humidity / 80° Fahrenheit.

• If you are unsure if your unit is classified as NSF/ANSI Type I or Type II, see tag

next to serial label on your case.

Check condensate pan float for proper operation (heat rod condensate system only).

Check that condensate pan is properly plugged in or connected.

Caution! Condensate pan may be malfunctioning (electrical heat rod condensate

system). If so, water will overflow pan and seep onto flooring causing damage! Until

condensate pan is functioning (or is replaced), following these procedures:

• Use wet-dry vacuum (or mop & bucket) to remove standing water.

• Use ‘catch pans’ for water to drain into. Swap out regularly until case has

completely drained.

Caution! Disruption of power can cause water to overflow pan and seep onto

flooring causing damage! Check that power to case is constant. Until power is

restored, following these procedures:

• Use wet-dry vacuum (or mop & bucket) to remove standing water.

• Use ‘catch pans’ for water to drainage. Swap out regularly until evaporation of

case is complete (or until power is restored).

When power to case is restored, condensate pan should function properly and water

will no longer overflow onto flooring.

Caution! Wicking material may be dirty or worn and need replacement (hot gas

condensate only).

• Slide refrigeration system out from under unit.

• After refrigeration system has been carefully slid out from under unit, replace

wicking material with new. If wicking material is not available, contact Structural

Concepts®. See toll-free number at last page of this operating manual.

TROUBLESHOOTING (TO BE PERFORMED BY TRAINED SERVICE PROVIDERS ONLY) - PAGE 1 of 3
