INSTALLATION, CONT’D: DISPLAY CASE START-UP

12. Display Case Start-Up

A. Case

• Remote Units: Case will power-up when properly

field wired.

• After case is powered up, open rear doors (or

front glass (see illustration below).

• If at case front, lift decking to check that coil fans

are running.

• Coil fans (and in self-contained units, compressor

motor) should turn on.

B. Lights

• Turn lights on.

> Remote Units: Switch is likely at rear plenum or

upright (as shown below).

• All lights should come on at the same time.

• Lighting is wired in series so all lights must be

plugged in or receptacles capped for case

lights to be on. See illustration at right.

• LED Lights may have single or dual rows

(depending upon model).

• Note: If lights do not come on, check that plug is

properly inserted into socket.

Light Switch
