CONDITION TROUBLESHOOTING

Case Not Lining Up See INSTALLATION section in this manual for instructions on properly aligning

case (alongside other cases) and adjusting levelers.

Water Is On The Floor Caution! Water on flooring can cause much damage! Until cause is determined

(and repaired), follow these procedures:

• Use wet-dry vacuum (or mop & bucket) to remove standing water.

• Use ‘catch pans’ for water to drain into. Swap out regularly until case has

completely drained.

Check that the drain trap is free of debris.

Check store conditions.

• To prevent condensation in NSF/ANSI Type I environments, maximum

conditions are to be 55% relative humidity / 75° Fahrenheit.

• For NSF/ANSI Type II environments, maximum conditions are to be 55%

relative humidity / 80° Fahrenheit.

• If you are unsure if your unit is classified as NSF/ANSI Type I or Type II,

see tag next to serial label on your case.

Fan Emits Excessive

Noise

Check that the case is aligned, level and plumb.

Check evaporator fans for cleanliness.

Unplug/power off fan motors. Check motor shaft for bearing wear.

Check that fan motors are securely mounted in brackets.

Verify that fan blades are securely mounted to fan motor.

Check that nothing is preventing blade rotation.

Check that the fan shroud is properly secured.

Fans Are Not Working Check that the MAIN power switch is on (or case is properly connected to power

source).

Check that fans are plugged in at the fan shroud.

Check for foreign material obstructing fan performance.

Check that fan blades freely rotate within fan shrouds

Check that power is going to fans

Check that fan wiring is connected on terminal blocks.

Digital Control Display

Is Blank

Check that the MAIN power switch is on.

Check the circuit breaker box for tripped circuits.

System Not Operating Check that the utility power is on.

Check that the MAIN power switch is on.

Check the circuit breaker box for tripped circuits.

TROUBLESHOOTING (TO BE PERFORMED BY TRAINED SERVICE PROVIDERS ONLY) - PAGE 1 of 2
