MAINTENANCE FUNDAMENTALS - HONEYCOMB AIR DIFFUSERS (SERVICE TECHNICIANS ONLY)

Honeycomb Air Diffuser Removal

See PREVENTIVE MAINTENANCE (TO BE

PERFORMED BY TRAINED SERVICE PROVIDER)

section in this manual for cleaning frequency.

A. Wedge a non-metallic device of suitable strength

(such as a ballpoint pen) between the honeycomb

and the end panel.

Caution! Use care not to dislodge the heating wire

(that prevents condensation on the lamp assembly).

B. Apply pressure to collapse the honeycomb to

allow it to be pulled out of honeycomb retainer.

C. Carefully pry downward and away from the

honeycomb retainer. Clean honeycomb with warm

water and soap solution. Submerse if necessary. Use

brush to dislodge stubborn or sticky residue. Dry by

using vacuum’s blow mode (vs. suction mode).

Honeycomb Air Diffuser Installation

D. Squeeze honeycomb to allow it to fit into the

honeycomb retainer.

E. Carefully slide honeycomb into place.

F. Adjust honeycomb so that it fits flat against

retainer. It must not be wavy or out of position.

Note: For honeycomb air diffusers in other

locations, these same general instructions apply.

Honeycomb
