21
MAINTENANCE, CONT’: REFRIG. PACKAGE ILLUSTRATION (FROM MODEL GHSS660R)
8. Refrigeration Package Configuration
• Illustration shown is from self-contained model GHDSS660R.
• Your particular refrigeration package may have a slightly different layout.
Compressor
Electrical Box
(Starter Unit &
Relay)
Filter
Dryer
Sight
Glass
Overflow Pan
(For Hot Gas
Condensate Pan)
Condenser Coil
Housing
Condenser Coil
Fans & Housing
Hot Gas
Condensate
Coils and
Pan
Overflow Pan
Electrical Box)
Receiver
Condenser
Coils
Hot Gas
Condensate
Coil Pan
