Fusion® User Manual 6

Oasis® B(L)24 User Manual 6

Installation: Case Removal From Skid

Remove Lower Front Panel From Case:

• To prevent damage to the case, remove the lower front

panel from the case before removing it from the pallet.

• The lower front is held in place by magnets only. No

screw removal is required.

• Place the lower front panel in a secure location while

removing the case from the pallet.

Remove Lower Rear Panel From Case:

• Remove the lower rear panel from the case before

removing it from the pallet.

• The lower rear is held in place by magnets only. No screw

removal is required.

• Place the lower rear panel in a secure location while

removing the case from the pallet.

Disconnect Case From Pallet:

• Remove screws from shipping brackets. Remove and

discard shipping brackets from the pallet.

• Raise the leveler all the way up to engage the casters.

Lower Front Panel

Lower Rear Panel

Shipping Bracket

Fusion® User Manual 6
