9
INSTALLATION: FRONT FAN ACCESS
8. Front Fan Access
Front Ballast Box
• Remove screws along outer area of case.
• Remove screws along inner area of case.
• Drop Front Fan panel down.
• Repair/replace fans.
• Replace in reverse order it was removed.
• Voltage rating is on serial label at case rear.
Note: Wiring process must be performed by
certified electrician only.
Remove screws along
outer area of case
Remove screws along
inner area of case
Front Fan
Panel
Front Fan
Panel
8
