MAINTENANCE FUNDAMENTALS - REAR SLIDING DOORS / THERMOMETER

Case With Single Set of Rear Sliding Doors

5. Rear Sliding Doors

Note: Doors are not interchangeable. There is an inner

and outer door.

• The outer door is the right hand door (from the service

side or rear of case).

• It is identified by a stop located at the lower right hand

corner to the inside of the case.

• To remove, move doors toward the center of the case.

• Outer door must be removed first and replaced last.

• Individually lift each door up toward the top

of the case; pivot the bottom of the door out.

• Carefully set rear sliding doors down to

prevent them from falling.

• Replace rear sliding doors in reverse order

they were removed.

6. Thermometer (Placement and Function)

• Thermometers are found at varying locations.

Illustration below shows rear placement. Yours may

vary.

• Thermometers provided with equipment reflect internal

air temperature only (NOT actual food temperature).

• Use probe thermometers to determine actual product

temperatures.
